✦Lighting

XND-1

Manufacturer
Swisson
Model
10 48 40
Code
GW-HUGZHC
Data status
Level 1 / 5
AI-parsed

❋ Specs

8
DMX universes
dmx_universes
2
1
DMX ports
dmx_ports
1 (configurable as input or output)
1
Protocols
protocols
Art-Net 1-4, sACN (incl. draft v0.2), RDM on outputs (ANSI E1.20)
1
Power
power_w
PoE IEEE 802.3af Class 2, or 5 V DC via USB
1
Ethernet
ethernet
10BASE-T / 100BASE-TX, auto MDI-X
1
Dimensions
dimensions
110 x 50 x 45mm
1
Weight
weight_kg
0.25kg
1
Operating temperature
operating_temperature_c
-20 to +50degC
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
