✦Moving Head (Spot/Wash/Beam)

VL3500 Spot

Manufacturer
Vari-Lite
Model
20.9678.0019
Code
GW-ZT8YQA
Data status
Level 1 / 5
AI-parsed

❋ Specs

17
Lamp
lamp_w
1200W
1
Lamp type
lamp_type
short arc / metal halide
1
Luminous flux
luminous_flux_lm
20000lm
1
Color temperature
color_temperature_k
6000K
1
CRI
cri
85
1
Pan
pan_deg
540deg
1
Tilt
tilt_deg
270deg
1
Zoom range
zoom_range_deg
10-60deg
1
Zoom ratio
zoom_ratio
6:1 (13-element)
1
Color mixing
color_mixing
CMY (CYM) cross-fading
1
Color wheel
color_wheel
6-position fixed color wheel + variable CTO
1
Gobo wheels
gobo_wheels
rotating wheel (5 indexable + open) + fixed wheel (6 + open)
1
Shutter
shutter
four-blade framing shutter (independent or in unison, two planes)
1
Control protocol
control_protocol
DMX-512
1
Frequency
frequency_hz
50/60Hz
1
Weight
weight_kg
41kg
1
Dimensions
dimensions
31.57"H x 20"W x 24"D (head vertical/horizontal)in
1
