✦System Processors

a-12

Manufacturer
VUE Audiotechnik
Model
a-12
Code
GW-5GHB1S
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Frequency range
frequency_range_hz
55-18000Hz
1
Max Long Term Spl Db
max_long_term_spl_db
122dB
1
Sensitivity
sensitivity_db
96 (passive) / 107 (bi-amp)dB
1
Horizontal coverage
horizontal_coverage_deg
70deg
1
Vertical coverage
vertical_coverage_deg
55deg
1
Nominal impedance
nominal_impedance_ohm
8ohm
1
Power Handling Average
power_handling_average_w
450W
1
Power Handling Program
power_handling_program_w
900W
1
Drivers
drivers
12-inch neodymium LF (3-inch / 75 mm VC) + neodymium HF compression driver (3-inch / 75 mm VC, 1.4-inch exit)
1
Horn
horn
70 x 55 deg rotatable horn; passive or bi-amp switchable
1
