✦System Processors

h-12

Manufacturer
VUE Audiotechnik
Model
h-12W / h-12N
Code
GW-S4HVAH
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Frequency range
frequency_range_hz
55-21000Hz
1
Sensitivity
sensitivity_db
96dB
1
Peak SPL
max_spl_peak_db
134dB
1
Max Long Term Spl Db
max_long_term_spl_db
119-120dB
1
Horizontal coverage
horizontal_coverage_deg
100 (W) / 60 (N)deg
1
Vertical coverage
vertical_coverage_deg
50 (W) / 40 (N)deg
1
Amplifier power
amplifier_power_w
830 (LF) + 275 (HF) long-term; >2400 peakW
1
Weight
weight_kg
35.19kg
1
Dimensions
dimensions_mm
610 x 368 x 387 (H x W x D)mm
1
Drivers
drivers
12-inch LF (4-inch / 100 mm VC) + beryllium HF compression driver (4-inch / 100 mm VC)
1
Processing
processing
Onboard VUEDrive engine, 96 kHz 64-bit DSP, 120 dB dynamic range, analog/AES-EBU input, network control
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
