✦Digital Mixers

XLA-308

Manufacturer
Wharfedale Pro
Model
XLA-308
Code
GW-XW1TNH
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Configuration
configuration
passive 3-way line array element
1
Drivers
drivers
2x 8" neodymium LF (2.5" v.c.) + B&C coaxial compression driver (3" MF / 2" HF v.c., 1.4" exit)
1
Frequency range
frequency_range_hz
58 - 20000Hz
1
Power
power_w
LF 700 / MHF 150 continuous; LF 1400 / MHF 300 program; LF 2800 / MHF 600 peakW
1
Sensitivity
sensitivity_db
112dB (2.83V/1m)
1
Impedance
impedance_ohm
LF 8 / MHF 8Ω
1
Crossover frequency
crossover_hz
500Hz
1
Horizontal coverage
horizontal_coverage_deg
110°
1
Vertical coverage
vertical_coverage_deg
0 - 10 splay (1° increments)°
1
Dimensions
dimensions
790 x 269.6 x 430.7 (W x H x D)mm
1
Weight
weight_kg
33kg
1
Cabinet material
cabinet_material
birch plywood, powder-coated steel grille
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
