✦Line Arrays

E15

Manufacturer
Adamson
Model
E15
Code
GW-QUDNUM
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Configuration
configuration
3-way true line source
1
Frequency range
frequency_range_hz
60 - 18000Hz
1
Max SPL
max_spl_db
147dB
1
Dispersion
dispersion_deg
90 x 6 (H x V)deg
1
Drivers
drivers
2x ND15-L 15" Kevlar Neodymium LF, 2x YX7 7" Neodymium MF, 2x NH4TA2 4" diaphragm / 1.5" exit HF compression driver
1
Power
power_w
LF 2x 800 AES / 2x 3200 peak; MF 700 AES / 2800 peak; HF 320 AES / 1280 peakW
1
Impedance
impedance_ohm
LF 2x 8; MF 16; HF 16ohm
1
Weight
weight_kg
79.8kg
1
Dimensions
dimensions
1306 W x 391 H (front) / 333 H (back) x 544 Dmm
1
Rigging
rigging
Autolock Rigging System
1
Connectors
connectors
2x Speakon NL8
1
Recommended amplifier
recommended_amplifier
Lab.gruppen PLM 20K44 / PLM 12K44 (Adamson E-Rack, with Lake DSP)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
PLM 5K44GW-VEQJZVPLM 20K44 BPGW-4V6XPVPLM 12K44GW-OYUWCSQuattrocanali 4804 DSP+DGW-VQZG86

Lab.gruppen PLM 20K44 / PLM 12K44 (Adamson E-Rack, with Lake DSP)
