✦Digital Mixers

dLive C1500

Manufacturer
Allen & Heath
Model
dLive C1500
Code
GW-S6F36F
Data status
Level 1 / 5
AI-parsed

❋ Specs

23
Configuration
configuration
12 faders, 6 layers (up to 72 fader strips)
1
Faders
faders
12
1
Layers
layers
6
1
Touchscreen In
touchscreen_in
12in
1
Softkeys
softkeys
19
1
Mic Line Inputs
mic_line_inputs
6XLR
1
Line Outputs
line_outputs
6XLR
1
Aes3 In
aes3_in
1 stereo
1
Aes3 Out
aes3_out
1 stereo
1
Io Port Channels
io_port_channels
128ch
1
Network ports
network_ports
2
1
Mixrack Link
mixrack_link
GigaACE (gigabit)
1
Sample rate
sample_rate_khz
96kHz
1
Frequency range
frequency_range_hz
20-30000 (+0/-0.8 dB)Hz
1
Dynamic range
dynamic_range_db
110dB
1
System Signal To Noise Db
system_signal_to_noise_db
-92dB
1
Analogue Gain
analogue_gain
+5 to +60 (1 dB steps)dB
1
Input Sensitivity Dbu
input_sensitivity_dbu
-60 to +15dBu
1
Latency
latency_ms
0.7 (MixRack XLR in to XLR out, input to mix)ms
1
Dimensions
dimensions
485 x 665 x 325 (W x D x H)mm
1
Weight
weight_kg
18kg
1
Power
power_w
110 (max)W
1
Mains
mains
100-240 V AC, 50-60 Hz
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
