✦Audio

DX168

Manufacturer
Allen & Heath
Model
DX168
Code
GW-AJTAYU
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Mic Line Inputs
mic_line_inputs
16ch
1
Line Outputs
line_outputs
8ch
1
Sample rate
sample_rate_khz
96kHz
1
Connectivity
connectivity
2x locking EtherCon DX link (gigaACE); redundant or cascade mode; for dLive / Avantis / SQ / AHM-64
1
Analog Gain Db
analog_gain_db
+5 to +60 (1 dB steps)dB
1
Max input level
max_input_level_dbu
+30 (pad in)dBu
1
Max output level
max_output_level_dbu
+22dBu
1
Mic Ein Dbu
mic_ein_dbu
-127 (150 ohm source)dBu
1
Power
power_w
35 (max)W
1
Dimensions Wxdxh
dimensions_wxdxh_mm
410 x 190 x 185mm
1
Weight
weight_kg
4.6kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
