✦Video Mixers / Scalers

Aquilon RS2

Manufacturer
Analog Way
Model
Aquilon RS2
Code
GW-K3GIJ9
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Inputs
inputs
16
1
Outputs
outputs
12 active + 2 dedicated multiviewer
1
Max resolution
max_resolution
4K60p, 10-12-bit 4:4:4 (80 Megapixels/s throughput on Program)
1
Connectors
connectors
8x HDMI 2.0, 4x DisplayPort 1.2/1.4, 4x 12G-SDI (field-swappable I/O cards)
1
Channels
channels
64x64Dante audio @48 kHz (or 32x32 @96 kHz)
1
Max layers
max_layers
up to 8x 4K mixing layers (16x 2K/DL, doubled if split layers)
1
Weight
weight_kg
29.3kg
1
Power
power_w
700W
1
Dimensions
dimensions_mm
482.4x177x712.5mm
1
Rack units
rack_units
4RU
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
