✦Video & Media

MMV1630

Manufacturer
AVMatrix
Model
MMV1630
Code
GW-JHQPSE
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
SDI inputs
sdi_inputs
16 (SD/HD/3G-SDI)
1
Loop Outputs
loop_outputs
16 (SD/HD/3G-SDI)
1
Multiview Outputs
multiview_outputs
2xSDI + 1xHDMI (scaling, with audio)
1
Matrix Size
matrix_size
16x16 (switcher mode)
1
Multiview Layouts
multiview_layouts
20 (16/12/11/10/9/8/6/4 presets)
1
Sdi Compliance
sdi_compliance
SMPTE 259M/292M/296M/372M/424M
1
Form factor
form_factor
1RU 19in rack
1
Dimensions
dimensions
482.5x148.6x44mm
1
Weight
weight_kg
2kg
1
Dc Input
dc_input_v
12-20 (redundant PS-1/PS-2)V
1
Power
power_w
36W
1
Operating temperature
operating_temperature_c
0 to 60C
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
