Monarch EDGE E4

Manufacturer
Matrox Video
Model
MDG4/E10/I2
Code
GW-2BYAVU
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Video inputs
video_inputs
4x 3G-SDI (or 1x 12G-SDI / quad 3G-SDI for single 4K)
1
Max resolution
max_resolution
2160p60 (4K), or 4x 1080p60
1
Video codec
video_codec
H.264/AVC High 4:2:2 10-bit (Hi422P)
1
Max Bitrate Mbps
max_bitrate_mbps
120Mbps
1
Audio channels
audio_channels
16 embedded SDI + 2 analog XLR (AAC-HE/AAC-LC)channels
1
Streaming protocols
streaming_protocols
SRT, MPEG-2 TS, RTSP
1
Glass To Glass Latency Ms
glass_to_glass_latency_ms
100ms
1
Network Interface
network_interface
2x SFP28 (up to 25 GbE)
1
Power
power_w
45W
1
Dimensions
dimensions
217 x 189 x 43mm
1
Weight
weight_kg
1.66kg
1
Rack Size
rack_size
1RU (two units side by side)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
