✦Video Mixers / Scalers

SHARK S8X PLUS

Manufacturer
AVMatrix
Model
SHARK S8X PLUS
Code
GW-GXNFXU
Data status
Level 1 / 5
AI-parsed

❋ Specs

14
Input channels
input_channels
8ch
1
SDI inputs
sdi_inputs
8 (3G/HD/SD-SDI)
1
HDMI inputs
hdmi_inputs
2 (4K HDMI)
1
Outputs
outputs
4xSDI PGM, 2xHDMI PGM, 1xHDMI multiview
1
Display
display_in
17.3in
1
Display type
display_type
FHD IPS (1920x1080)
1
Streaming
streaming
RTMP(S)/SRT/RTSP (NDI optional)
1
Recording
recording
USB / SD card / 2.5in SATA SSD (MP4/TS up to 1080p60 32Mbps)
1
Audio Inputs
audio_inputs
2xXLR/TRS balanced (48V phantom) + 3.5mm stereo
1
Ptz Control
ptz_control
8-ch (Visca, Onvif, Pelco P/D)
1
Dimensions
dimensions
433x307x75.5mm
1
Weight
weight_kg
5.5kg
1
Dc Input
dc_input_v
9-24 (working 15V)V
1
Power
power_w
50W
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
