✦Video Mixers / Scalers

ATEM 4 M/E Constellation HD

Manufacturer
Blackmagic Design
Model
SWATEMCONSTLN4ME
Code
GW-SU8QFQ
Data status
Level 1 / 5
AI-parsed

❋ Specs

33
Me Buses
me_buses
4M/E
1
Video inputs
video_inputs
40шт
1
Video outputs
video_outputs
24шт
1
Aux Outputs
aux_outputs
6шт
1
Multiview Outputs
multiview_outputs
2шт
1
Formats
supported_formats
1080p60, 1080p50, 1080p30, 1080p25, 1080p24, 1080i60, 1080i50, 720p60, 720p50
1
Upstream Keyers Per Me
upstream_keyers_per_me
4шт
1
Downstream Keyers
downstream_keyers
2шт
1
Dve Per Me
dve_per_me
1шт
1
Chroma Keyers Per Me
chroma_keyers_per_me
1шт
1
Color Generators
color_generators
2шт
1
Media Players
media_players
2шт
1
Media Pool Stills
media_pool_stills
64шт
1
Audio Inputs
audio_inputs
40шт
1
Audio Mixer Channels
audio_mixer_channels
40шт
1
Talkback
talkback
yes
1
Usb Streaming
usb_streaming
yes
1
Control interface
control_interface
Ethernet (ATEM Software Control, ATEM Hardware Panel)
1
Form factor
form_factor
rack-mount
1
Rack units
rack_units
4U
1
Weight
weight_kg
5.0kg
1
Power
power_w
95W
1
Connector Video In
connector_video_in
12G-SDI (BNC)
1
Connector Video Out
connector_video_out
12G-SDI (BNC)
1
Connector Ref In
connector_ref_in
2× BNC (Bi-level/Tri-level sync)
1
Control Connector
control_connector
2× RJ-45 Ethernet
1
Os Compatibility
os_compatibility
macOS, Windows
1
Manufacturer
manufacturer
Blackmagic Design
1
Channels
channels
156audio channels
1
Dimensions
dimensions_mm
482x231x88mm
1
Inputs
inputs
403G-SDI
1
Max resolution
max_resolution
1080p60
1
Outputs
outputs
243G-SDI
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
