✦Moving Head (Spot/Wash/Beam)

Diablo

Manufacturer
Ayrton
Model
AY-DIABLO
Code
GW-FYZ3NJ
Data status
Level 1 / 5
AI-parsed

❋ Specs

26
Manufacturer
manufacturer
Ayrton
1
Light source
light_source
LED (white multi-chip)
1
Source Power
source_power_w
250W
1
Luminous flux
luminous_flux_lm
≈ 9 000lm
1
Color temperature
color_temperature_k
6 500K
1
CRI
cri
≥ 70
1
Zoom range
zoom_range_deg
3 – 49°
1
Pan range
pan_range_deg
540°
1
Tilt range
tilt_range_deg
270°
1
Rotating gobos
rotating_gobos
6 + open
1
Gobos Fixed
gobos_fixed
6 + open
1
Prisms
prisms
2 (4-facet + 8-facet)
1
Frost Filters
frost_filters
2
1
Color wheel
color_wheel
13 colors + open
1
Cto Correction
cto_correction
yes
1
Iris
iris
yes
1
Strobe rate
strobe_hz
1 – 25Hz
1
Dimmer
dimmer
0 – 100 %
1
Control protocol
control_protocol
DMX-512 / RDM
1
DMX channels
dmx_channels
16 / 26
1
Wireless Dmx
wireless_dmx
optional (Lumen Radio CRMX)
1
Display
display
OLED
1
Power consumption
power_consumption_w
350 (max.)W
1
Weight
weight_kg
12.1kg
1
Dimensions
dimensions_mm
330 × 230 × 530 (D × W × H)mm
1
Certifications
certifications
CE, UKCA
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
