✦Moving Head (Spot/Wash/Beam)

Khamsin-S

Manufacturer
Ayrton
Model
011640
Code
GW-NPURRE
Data status
Level 1 / 5
AI-parsed

❋ Specs

25
Led Module
led_module_w
750W
1
Luminous output
luminous_output_lm
40000lm
1
Color temperature
color_temperature_k
7000K
1
CRI
cri
>70
1
Led Life L70 H
led_life_l70_h
40000h
1
Zoom range
zoom_range_deg
7-58deg
1
Zoom ratio
zoom_ratio
8:1
1
Optical System
optical_system
13-element lens assembly, 158 mm frontal lens
1
Front lens
front_lens_mm
158mm
1
Color mixing
color_mixing
CMY + variable CTO + 6-position fixed color wheel
1
Gobo wheels
gobo_wheels
2 rotating wheels, 6 HD glass gobos each (34 mm)
1
Framing System
framing_system
4 individually positionable shutter blades, +/-45 deg rotation
1
Prisms
prisms
2 rotating (5-facet circular, 4-facet linear)
1
Iris
iris
15-blade diaphragm
1
Frost
frost
2 filters (light and heavy)
1
Pan
pan_deg
540deg
1
Tilt
tilt_deg
262deg
1
Control protocols
control_protocols
DMX-512, Art-Net, sACN, RDM, CRMX TiMo wireless
1
DMX channels
dmx_channels
40-64 selectable
1
Cooling
cooling
liquid cooling with variable-speed fans, Silent Mode
1
Power consumption
power_consumption_w
1150W
1
Mains Frequency Hz
mains_frequency_hz
50/60Hz
1
Dimensions
dimensions
494 x 778 x 280mm
1
Weight
weight_kg
39.8kg
1
Operating temperature
operating_temperature
-10 to +45C
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
