Tessera R2

Manufacturer
Brompton Technology
Model
Tessera R2
Code
GW-URWHEX
Data status
Level 1 / 5
AI-parsed

❋ Specs

9
Pixel Capacity
pixel_capacity
262144RGB px
1
Bit depth
bit_depth
16bit per channel
1
Network
network
2x Gigabit Ethernet (1000BASE-T)
1
Output Data Channels
output_data_channels
up to 144
1
Led Driver Chains
led_driver_chains
up to 36 (up to 72 with Virtual Channels)
1
Dimensions
dimensions
67.6 x 31.9mm
1
Form factor
form_factor
200-pin DDR2 SO-DIMM
1
Led Drivers
led_drivers
all major driver ICs supported
1
Compatible Processors
compatible_processors
Tessera SX40, S8, S4, T1; XD Data Distribution Unit
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Processors
X4GW-MZGZS0

Tessera SX40, S8, S4, T1; XD Data Distribution Unit

❋ Where to repair

Brompton Technology · authorized service
Red Rock OPS LLC (Brompton Hydra calibration partner)Las Vegas, US↗
