✦Digital Mixers

SD10

Manufacturer
DiGiCo
Model
SD10
Code
GW-WVNFMH
Data status
Level 1 / 5
AI-parsed

❋ Specs

20
Input channels
input_channels
144
1
Faders
faders
37 x 100mm touch-sensitive motorised
1
Touchscreen
touchscreen
15inch
1
Assignable Busses
assignable_busses
64
1
Master Buss
master_buss
LR/LCR/LCRS/5.1
1
Matrix
matrix
24 x 24
1
Control Groups
control_groups
24
1
Dynamic Eq
dynamic_eq
218
1
Multiband Compressors
multiband_compressors
218
1
Graphic Eq
graphic_eq
24 x 32-band
1
Fx Processors
fx_processors
24 stereo
1
Meters
meters
38 x 20-segment LED bargraph
1
Processing
processing
Stealth Digital Processing, up to 40-bit floating point
1
Sample rate
sample_rate_khz
44.1 / 48 / 96kHz
1
Converter Bit Depth
converter_bit_depth
24bit
1
Processing Delay Ms
processing_delay_ms
2ms @ 48kHz, 1.1ms @ 96kHz
1
Local Io
local_io
8 mic/line in, 8 line out, 8 AES/EBU mono I/O, 2 redundant MADI
1
Dimensions
dimensions
1398 x 818 x 285mm
1
Weight
weight_kg
60kg
1
Power
power_w
235W
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Processors

24 stereo
