✦Truss: Straight / Corners

DT 33/2-300

Manufacturer
DuraTruss
Model
1723100015
Code
GW-RUM4YE
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Length
length_mm
3000mm
1
Width
width_mm
290mm
1
Height
height_mm
257mm
1
Weight
weight_kg
11.7kg
1
Main tube diameter
main_tube_diameter_mm
50mm
1
Main Tube Wall Thickness
main_tube_wall_thickness_mm
2mm
1
Brace Diameter
brace_diameter_mm
20mm
1
Brace Wall Thickness
brace_wall_thickness_mm
2mm
1
Alloy
alloy
EN-AW 6082 T6 (AlMgSi1)
1
Coupling System
coupling_system
Conical adapter with steel pin and safety clip
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
