✦Line Arrays

NTL720

Manufacturer
EAW
Model
NTL720
Code
GW-F6Z9YM
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

10
Frequency range
frequency_range_hz
75-19000Hz
1
Max SPL
max_spl_db
128 (MF, calculated peak)dB
1
Horizontal coverage
horizontal_coverage_deg
110deg
1
Vertical coverage
vertical_coverage_deg
12deg
1
Drivers
drivers
2x 6-in LF cone (1.75-in VC), 2x 6-in MF cone (1.75-in VC), 6x 1-in HF dome
1
Amplifier power
amplifier_power_w
1500 (LF 500W, MF 500W, HF 500W @ 4 ohm)W
1
Dimensions
dimensions
239 x 610 x 363 (9.41 x 24 x 14.28 in)mm
1
Weight
weight_kg
21.5kg
1
Enclosure type
enclosure_type
compact self-powered 3-way line array module
1
Connectors
connectors
XLR analog / AES-EBU loop, 2x U-NET, USB, 2x PowerCon loop
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
