✦Video & Media

BrightEye 72

Manufacturer
Ensemble Designs
Model
BE72
Code
GW-DYPI8X
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Sdi Input Rates
sdi_input_rates
SD 270 Mb/s, HD 1.485 Gb/s, 3G 2.97 Gb/s
1
Sdi Formats
sdi_formats
525i, 625i, 1080i, 720p, 1080p, 1080sF
1
Hdmi Output
hdmi_output
1 (HDMI 1.3, format follows input)
1
Sdi Loopback Outputs
sdi_loopback_outputs
1 (delay < 5 us)
1
Analog Audio Output Channels
analog_audio_output_channels
8
1
Embedded Audio Meters
embedded_audio_meters
16 (on-screen VU)
1
Color Correction
color_correction
yes (full proc amp)
1
Power
power_w
7W
1
Dimensions
dimensions_mm
143 x 21 x 152mm
1
Weight
weight_kg
0.40kg
1
Ac Input Vac
ac_input_vac
100-230VAC
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
