✦Video & Media

DTP T HD2 4K 230

Manufacturer
Extron
Model
60-1491-12
Code
GW-GYOSF2
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

11
Function
function
DTP transmitter for HDMI with input loop-through
1
Signal Type
signal_type
HDMI, HDCP; HDBaseT-compatible
1
Max Data Rate Gbps
max_data_rate_gbps
10.2 (3.4 per color)Gbps
1
Max Pixel Clock Mhz
max_pixel_clock_mhz
300MHz
1
Color depth
color_depth_bit
up to 12-bit deep color
1
Transmission Distance 1080P
transmission_distance_1080p
230 ft / 70 m over STP / XTP DTP 24
1
Transmission Distance 4K
transmission_distance_4k
130 ft / 40 m over STP / XTP DTP 24
1
Io
io
1 HDMI in + 1 HDMI loop-through, 1 DTP out; RS-232 + IR pass-through
1
Dimensions
dimensions
1.0 H x 4.3 W x 6.0 D (quarter rack wide)in
1
Weight
weight_kg
0.3kg
1
Power
power_w
7.5 (device and power supply)W
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
