✦Lighting

DIN Ethergate Mk2

Manufacturer
Enttec
Model
71031
Code
GW-LONJJS
Data status
Level 1 / 5
AI-parsed

❋ Specs

9
DMX universes
dmx_universes
2 bi-directional
1
Max Channels Per Port
max_channels_per_port
4096 (Overdrive mode)
1
Dmx Speed K
dmx_speed_k
250 / 500 / 750 / 1000K
1
Protocol
protocol
Art-Net, Art-RDM, sACN, ESP, KiNET
1
Connectors
connectors
2x Ethernet RJ45 (1x PoE), 2x DMX (pluggable terminal)
1
Input voltage
input_voltage_v
12-24V DC
1
PoE
poe
Yes (one port)
1
Power
power_w
7W
1
Mounting
mounting
4-DIN-module housing, TS35 DIN-rail / wall
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
