✦Video Mixers / Scalers

HVS-1200

Manufacturer
FOR-A
Model
HVS-1200
Code
GW-FG8VGW
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Video formats
video_formats
4K UHD 2160p/59.94,50 via single-link 12G-SDI or quad-link 3G-SDI; HD 3G/HD-SDI 1080p/i
1
Video inputs
video_inputs
10 (4K) / 40 (HD), all with frame synchronizer
1
Me Count
me_count
1 M/E (4K) / 2 M/E + 4 MELite (HD), 6 M/E performance
1
Keyers
keyers
2 per M/E (4K) / 4 per M/E + 4 FLEXaKEY (HD)
1
Weight
weight_kg
18kg
1
Dimensions
dimensions
430 x 132 x 490 (480 W incl. rack brackets)mm
1
Rack units
rack_units
3RU
1
Power
power_w
540 (at 100-120 V), 506 (at 220-240 V); full option 640W
1
Power supply
power_supply
AC 100-240 V +/-10% 50/60 Hz
1
Operating temperature
operating_temperature
0 to 40C
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
