✦Truss: Straight / Corners

General Purpose 20.5in Triangle Truss

Manufacturer
James Thomas Engineering
Model
General Purpose 20.5in Triangle Truss
Code
GW-JFS5CQ
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Material
material
6061-T6 / 6082-T6 aluminium
1
Cross section
cross_section_mm
590.6mm
1
Tube outer diameter
tube_outer_diameter_mm
50.8mm
1
Wall thickness
wall_thickness_mm
3.2mm
1
Length
length_m
3.05m
1
Weight
weight_kg
29.9kg
1
Max Uniform Load Kg 3M Span
max_uniform_load_kg_3m_span
2540kg
1
Max Point Load Kg 3M Span
max_point_load_kg_3m_span
1270kg
1
Truss Shape
truss_shape
equilateral triangle, 60°
1
Product Code
product_code
B0500 (10 ft section)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
