✦Point Source / Full-Range

EON715

Manufacturer
JBL Professional
Model
EON715
Code
GW-6IBV0M
Data status
Level 1 / 5
AI-parsed

❋ Specs

31
Driver Woofer Diameter Inch
driver_woofer_diameter_inch
15
1
Driver Tweeter Diameter Inch
driver_tweeter_diameter_inch
1
1
Peak power
power_peak_w
1300
1
RMS power
power_rms_w
650
1
Max SPL
max_spl_db
128
1
Frequency Range 10Db Hz Low
frequency_range_10db_hz_low
45
1
Frequency Range 10Db Hz High
frequency_range_10db_hz_high
20000
1
Frequency Range 3Db Hz Low
frequency_range_3db_hz_low
55
1
Frequency Range 3Db Hz High
frequency_range_3db_hz_high
20000
1
Horizontal coverage
horizontal_coverage_deg
90
1
Vertical coverage
vertical_coverage_deg
60
1
Crossover frequency
crossover_hz
1900
1
Impedance Lf Ohm
impedance_lf_ohm
4
1
Impedance Hf Ohm
impedance_hf_ohm
8
1
Height
height_mm
702
1
Width
width_mm
438
1
Depth
depth_mm
351
1
Weight
weight_kg
17
1
Gross Weight
gross_weight_kg
21.5
1
Audio Inputs
audio_inputs
2x XLR Combo, 1x XLR passthrough
1
Input Impedance Balanced Kohm
input_impedance_balanced_kohm
100
1
Input Impedance Unbalanced Kohm
input_impedance_unbalanced_kohm
50
1
Gain Range Db
gain_range_db
-∞ to +36
1
Bluetooth
bluetooth
yes
1
Dsp Features
dsp_features
dbx: automatic feedback suppression, music reduction, 100ms delay, parametric EQ
1
Cooling
cooling
passive
1
Enclosure material
enclosure_material
PP+10% Talc with 16GA perforated steel grille
1
Pole Socket Diameter
pole_socket_diameter_mm
36
1
Handles
handles
2, with cable channel on bottom panel
1
Rigging Points
rigging_points
4x M10
1
Amplification
amplification
Self-powered (built-in amplifier)
1
