✦Subwoofers

VTX B15

Manufacturer
JBL Professional
Model
VTX B15
Code
GW-JH2IOI
Data status
Level 1 / 5
AI-parsed

❋ Specs

20
Frequency range
frequency_range_hz
35–95Hz
1
Frequency Range Preset Hz
frequency_range_preset_hz
80Hz
1
Max SPL
max_spl_db
132dB
1
Spl Measurement Distance
spl_measurement_distance_m
1m
1
Continuous power
power_continuous_w
1300W
1
Power Rating
power_rating
IEC/100 hour
1
Nominal impedance
nominal_impedance_ohm
8Ω
1
Impedance Minimum Ohm
impedance_minimum_ohm
6.1Ω
1
Driver Model
driver_model
JBL 2285H, 15 inches, dual 4-inch voice coils
1
Driver Technology
driver_technology
Neodymium Differential Drive
1
Enclosure material
enclosure_material
Birch plywood (15/18/24 mm)
1
Enclosure Finish
enclosure_finish
Black DuraFlex
1
Width
width_mm
464mm
1
Height
height_mm
536mm
1
Depth
depth_mm
586mm
1
Weight
weight_kg
41.5kg
1
Connector type
connector_type
Neutrik speakON STX
1
System type
system_type
Passive Subwoofer
1
Radiation Pattern
radiation_pattern
Omnidirectional / Cardioid (selectable)
1
Recommended amplifier
recommended_amplifier
Crown I-Tech 4x3500HD / I-Tech 12000HD
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
I-Tech 4x3500HDGW-831O2DI-Tech 12000HDGW-5TZENG

Crown I-Tech 4x3500HD / I-Tech 12000HD
