✦Lighting

Clubmax 3000 FB4

Manufacturer
Kvant Lasers
Model
Clubmax 3000 FB4
Code
GW-N1UVMK
Data status
Level 1 / 5
AI-parsed

❋ Specs

14
Total Output Power
total_output_power_w
3W
1
Red Output
red_output_w
0.7W
1
Green Output
green_output_w
1.25W
1
Blue Output
blue_output_w
1.5W
1
Wavelengths
wavelengths_nm
637 / 525 / 445nm
1
Scanner Type
scanner_type
ScannerMAX 506 Compact
1
Scan speed
scan_speed_kpps
40 @ 8°kpps
1
Scan angle
scan_angle_deg
60deg
1
Beam divergence
beam_divergence_mrad
0.5mrad
1
Beam diameter
beam_diameter_mm
4.5 x 4.5mm
1
Control interface
control_interface
FB4-SK (Ethernet, ArtNet, DMX, ILDA)
1
Power consumption
power_consumption_va
340VA
1
Weight
weight_kg
8.8kg
1
Dimensions
dimensions_mm
294 x 168 x 270mm
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
