✦Lighting

ClubMAX 3000 FB4

Manufacturer
Kvant
Model
Clubmax 3000 FB4
Code
GW-NEXKWM
Data status
Level 1 / 5
AI-parsed

❋ Specs

24
Guaranteed Optical Output
guaranteed_optical_output_w
3W
1
Power R
power_r_w
0.7W
1
Power G
power_g_w
1.25W
1
Power B
power_b_w
1.5W
1
Wavelengths Rgb Nm
wavelengths_rgb_nm
637 / 525 / 445 (±5)nm
1
Scanner
scanner
ScannerMAX 506 Compact
1
Scan speed
scan_speed_kpps
40 @ 8°kpps
1
Scan angle
scan_angle_deg
60°
1
Beam Size
beam_size_mm
4.5 x 4.5mm
1
Beam divergence
beam_divergence_mrad
0.5mrad
1
Modulation Khz
modulation_khz
Analog 100kHz
1
Power consumption
power_consumption_va
340VA
1
Weight
weight_kg
8.8kg
1
Dimensions
dimensions
294 x 168 x 270 (WxHxD)mm
1
Connectors
connectors
Neutrik powerCON TRUE1
1
Dimensions
dimensions_mm
294x168x270 (WxHxD)mm
1
Inputs
inputs
Ethernet, ArtNet, DMX512, ILDA (FB4-SK controller)
1
Power
power_w
3W
1
Scanning Angle Deg
scanning_angle_deg
60deg
1
Wavelength
wavelength_nm
637/525/445 (R/G/B)nm
1
Colours
colours
RGB (full-colour)
ILDA
ilda
Yes (ILDA in/out, Ethernet, ArtNet, DMX via FB4-SK)
Laser power
laser_power_mw
3000mW
Safety class
safety_class
Class 4 (EN 60825-1, TUV SUD tested, FDA)
