✦Lighting

CS-1000RGB MK4

Manufacturer
Laserworld
Model
CS-1000RGB MK4 (EAN 7640144997496)
Code
GW-KUA9T6
Data status
Level 1 / 5
AI-parsed

❋ Specs

18
Total Power Mw
total_power_mw
1000mW
1
Guaranteed Power Mw
guaranteed_power_mw
800mW
1
Red power
power_red_mw
200mW
1
Green power
power_green_mw
70mW
1
Blue power
power_blue_mw
530mW
1
Wavelength Red Nm
wavelength_red_nm
650nm
1
Wavelength Green Nm
wavelength_green_nm
520nm
1
Wavelength Blue Nm
wavelength_blue_nm
445nm
1
Scan speed
scan_speed_kpps
28kpps @ 8° ILDA
1
Beam divergence
beam_divergence_mrad
1.1mrad
1
Beam diameter
beam_diameter_mm
4mm
1
Modulation
modulation
analogue
1
Power consumption
power_consumption_w
20W
1
Weight
weight_kg
2.5kg
1
Dimensions
dimensions
220 x 150 x 116mm
1
Colours
colours
RGB (red 200mW/650nm, green 70mW/520nm, blue 530mW/450nm)
ILDA
ilda
Yes (ILDA, DMX)
Laser power
laser_power_mw
1000mW

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
