OBD 1210

Manufacturer
LYNX Technik
Model
OBD 1210
Code
GW-AMIYDS
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Signal Type
signal_type
MADI bidirectional (64 IN & 64 OUT)
1
Coax Io
coax_io
1x BNC in + 1x BNC out (75 Ohm)
1
Fiber Wavelength Nm
fiber_wavelength_nm
1310 / 1550 (WDM, single bidirectional fiber)nm
1
Fiber Connector
fiber_connector
1x LC bidirectional (singlemode)
1
Max Distance Km
max_distance_km
10 (singlemode)km
1
Power
power_w
2.6 per moduleW
1
Power Supply Vdc
power_supply_vdc
12 (range 7-16)V DC
1
Dimensions
dimensions
140 x 42 x 22mm
1
Weight
weight_g
125 per moduleg
1
Kit Contents
kit_contents
matched pair (Type A + Type B), 2x PSU, transport case
1
