SPG 1707

Manufacturer
LYNX Technik
Model
SPG 1707
Code
GW-PVD1GL
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Hd Sync Outputs
hd_sync_outputs
3x tri-level HD analog sync (SMPTE 274M/296M)
1
Sd Sync Outputs
sd_sync_outputs
3x SD bi-level sync (NTSC/PAL/PAL M-N, SMPTE 170M)
1
Supported Standards
supported_standards
1080i, 1080p, 1080psf, 720p
1
Audio Reference
audio_reference
48KHz Word Clock or DARS (SMPTE 276M AES)
1
Genlock
genlock
bi-level or tri-level analog sync, cross-lock 525/625 + HD
1
Accuracy Ppm
accuracy_ppm
2ppm
1
Power
power_w
2.3W
1
Power Supply Vdc
power_supply_vdc
12 (range 8-17)V DC
1
Dimensions
dimensions
140 x 90 x 22mm
1
Weight
weight_g
300g
1
EAN
ean
4250479317079
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
