✦Line Arrays

CAL 64

Manufacturer
Meyer Sound
Model
CAL 64
Code
GW-BXL2I1
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Configuration
configuration
self-contained steerable column array, center split
1
Drivers
drivers
16x 4-inch cone drivers + 48x 20 mm tweeters
1
Amplifier
amplifier
multichannel Class D, one channel per driver, 64 channels
1
Frequency range
frequency_range_hz
100-16000Hz
1
Max SPL
max_spl_db
101dB
1
Weight
weight_kg
56.2kg
1
Dimensions
dimensions
2228 x 197 x 252 (HxWxD)mm
1
Horizontal coverage
horizontal_coverage_deg
120deg
1
Vertical coverage
vertical_coverage_deg
5-30deg
1
Beam Steering Deg
beam_steering_deg
+/-30deg
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
