✦Line Arrays

XSLi

Manufacturer
d&b audiotechnik
Model
XSLi8, XSLi12
Code
GW-GBMZZA
Data status
Level 1 / 5
AI-parsed

❋ Specs

20
Weight
weight_kg
39kg
1
Width
width_mm
700mm
1
Height
height_mm
283mm
1
Depth
depth_mm
507mm
1
Frequency range
frequency_range_hz
60 – 18000Hz
1
Max Spl 1M Db
max_spl_1m_db
140–141dB
1
Power Front Lf W Rms
power_front_lf_w_rms
400W
1
Power Front Lf W Peak
power_front_lf_w_peak
1200W
1
Power Side Lf Mf Hf W Rms
power_side_lf_mf_hf_w_rms
300W
1
Power Side Lf Mf Hf W Peak
power_side_lf_mf_hf_w_peak
850W
1
Horizontal Dispersion Xsli8 Deg
horizontal_dispersion_xsli8_deg
80°
1
Horizontal Dispersion Xsli12 Deg
horizontal_dispersion_xsli12_deg
120°
1
Tilt Angle Range Deg
tilt_angle_range_deg
0 – 14°
1
Max Cabinet Count
max_cabinet_count
12шт
1
Connector type
connector_type
speakON NLT4 F/M
1
Driver Front Lf Inch
driver_front_lf_inch
2× 8"
1
Driver Side Lf Inch
driver_side_lf_inch
2× 6.5"
1
Driver Mf Inch
driver_mf_inch
1× 6.5"
1
Driver Hf Inch
driver_hf_inch
2× 1" compression
1
Recommended amplifier
recommended_amplifier
d&b D40 / D80 / D90 / 40D
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D40GW-VLG5AOD80GW-W0VOZ9

d&b D40 / D80 / D90 / 40D
