✦Point Source / Full-Range

45N-12

Manufacturer
Nexo
Model
45N-12
Code
GW-CQ1SMM
Data status
Level 1 / 5
AI-parsed

❋ Specs

13
Drivers
drivers
LF 1 x 12" (30 cm) high excursion Neodymium 8Ω driver; HF 1 x 3" voice coil, 1.4" throat Neodymium 16Ω compression driver on a 22.5° hyperboloid reflective wavesource
1
Configuration
configuration
2-way active or passive (internally configurable)
1
Frequency range
frequency_range_hz
55 - 19000 (±3 dB); usable 50 - 20000 @ -6 dBHz
1
Max SPL
max_spl_db
137 to 140 (1 unit) / 140 to 143 (2 units), peakdB
1
Sensitivity
sensitivity_db
106 SPL nominal / 104 SPL wideband (1W @ 1m)dB
1
Crossover frequency
crossover_hz
1000 (LF-HF, active or passive)Hz
1
Impedance
impedance_ohm
Active LF 8, HF 16; Passive 8Ω
1
Amplifier
amplifier
Active LF 1000 to 1500 W 8Ω / HF 250 to 500 W 16Ω; Passive 1200 to 2000 W 8Ω (with NEXO NX TD Controller)
1
Dispersion
dispersion_deg
30° horizontal (scalable in 30° steps), 22.5° diagonal coupling plane, 60° vertical asymmetrical (-45°/+15°)
1
Dimensions
dimensions
392 x 492 x 576 (H x W x D)mm
1
Weight
weight_kg
24kg
1
Connectors
connectors
2 x NL4MP Speakon 4-pole
1
Recommended amplifier
recommended_amplifier
NEXO NXAMP4x1mk2 / NXAMP4x4mk2 (powered digital controller, NXAMPmk2 series)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
NXAMP4x1mk2GW-VOLAF0NXAMP4x4mk2GW-ELDARVK2GW-ORJJ8E

NEXO NXAMP4x1mk2 / NXAMP4x4mk2 (powered digital controller, NXAMPmk2 series)
