✦Point Source / Full-Range

NX 985-A

Manufacturer
RCF
Model
13000743
Code
GW-R7D6MS
Data status
Level 1 / 5
AI-parsed

❋ Specs

13
Configuration
configuration
3-way active
1
Drivers
drivers
1 x 15" woofer (3.0" v.c) + 1 x 8" neo midrange (2.5" v.c) + 1 x 1.0" neo compression driver (1.75" v.c)
1
Frequency range
frequency_range_hz
40 - 20000Hz
1
Max SPL
max_spl_db
138dB
1
Dispersion
dispersion_deg
100 x 60degrees
1
Amplifier
amplifier
2100 W Peak (Low 1400 W / Mid 500 W / High 200 W)
1
Power
power_w
2100W
1
Crossover Frequencies
crossover_frequencies
Bass/Mid 320, Mid/High 1200Hz
1
Input connectors
input_connectors
Combo XLR/Jack
1
Output connectors
output_connectors
XLR
1
Weight
weight_kg
45kg
1
Dimensions
dimensions
1075 x 461 x 475mm
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
