✦Staging & Structures

AS 7

Manufacturer: Stahl CraneSystems
Model: AS 7
Code: GW-4NITIB

Data status

Level 1 / 5

AI-parsed

❋ Specs

Load capacity

load_capacity_kg

up to 80000 (single); up to 125000 as AS 7 ZW twin hoistkg

Reeving

reeving

2/1, 4/1, 6/1, 10/2-1 (single); ZW 4/2-1, 6/2-1, 8/2-1, 10/2-1 (twin)

Rope Drum

rope_drum

double-grooved rope drum; TDC Twin Drive Concept

Hoist Motor

hoist_motor

cylindrical rotor motor with monodisc spring-loaded brake

Travel Speed M Min

travel_speed_m_min

5/20 (2-speed, 50 Hz); 2.5...25 frequency-controlledm/min

Supply voltage

supply_voltage_v

380-415 (50 Hz) / 440-480 (60 Hz)V

Wire Rope

wire_rope

to DIN EN 12385, bright or galvanised, safety factor >= 4.0

Ambient Temperature C

ambient_temperature_c

-20 to +40 standard (-40 to +80 optional)C

Overload Protection

overload_protection

SLE (standard) / SMC (optional)

Explosion Protection

explosion_protection

optional ATEX/IECEx, NEC, CEC, INMETRO, TC RU

Classification

classification

FEM/ISO

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
