✦Staging & Structures

ST 60

Manufacturer: Stahl CraneSystems
Model: ST 60
Code: GW-YUZY8R

Data status

Level 1 / 5

AI-parsed

❋ Specs

Load capacity

load_capacity_kg

3200-6300kg

Reeving

reeving

1/1 only in standard programme (largest ST size)

Hoisting Speed M Min

hoisting_speed_m_min

2-speed pole-changing (typ. 8/2 or 4/1), also frequency-controlled (STF)m/min

Supply voltage

supply_voltage_v

380-415; 50/60 HzV

Load Chain

load_chain

grade 8 to DIN 5684, galvanised, safety factor > 5.0; oil-bath slipping clutch

Hoist Brake

hoist_brake

monodisc spring-loaded electromagnetic disc brake, asbestos-free linings

Control Type

control_type

contactor control; optional Magnetek variable-frequency drive + radio remote

Explosion Protection

explosion_protection

optional ATEX/IECEx Zone 1, 21, 22

Classification

classification

FEM/ISO

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
