✦Staging & Structures

ST 30

Manufacturer
Stahl CraneSystems
Model
ST 30
Code
GW-IDDQJY
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Load capacity
load_capacity_kg
1250-3200kg
1
Reeving
reeving
1/1 or 2/1
1
Power
power_w
2300/570 (2.3/0.57 kW, 2-speed, 50 Hz, 3200 kg 2/1 variant)W
1
Power 60Hz
power_60hz_w
2800/680 (2.8/0.68 kW, 60 Hz)W
1
Hoisting Speed M Min
hoisting_speed_m_min
4/1 (3200 kg, 2-speed 50 Hz)m/min
1
Supply voltage
supply_voltage_v
380-415; 50/60 HzV
1
Headroom Hook To Beam
headroom_hook_to_beam_mm
185 (STK short-headroom, 3200 kg)mm
1
Load Chain
load_chain
grade 8 to DIN 5684, galvanised, safety factor > 5.0; oil-bath slipping clutch
1
Hoist Brake
hoist_brake
monodisc spring-loaded electromagnetic disc brake, asbestos-free linings
1
Control Type
control_type
contactor control; STH 1 pendant with emergency stop
1
Classification
classification
FEM/ISO
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
