✦Staging & Structures

Winch 50

Manufacturer
Wahlberg Motion Design
Model
.245.3
Code
GW-11Y63R
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Lifting Capacity
lifting_capacity_kg
50kg
1
Lifting height
lifting_height_m
12.5m
1
Lifting Speed Cm S
lifting_speed_cm_s
3-100cm/s
1
Voltage (AC)
voltage_vac
200-240VAC
1
Power
power_w
825W
1
Motor
motor
230 VAC, 0.55 kW
1
DMX channels
dmx_channels
6
1
Lifting Wire
lifting_wire
3 mm 19x7 galvanized steel
1
Min Wire Breaking Load
min_wire_breaking_load_kg
588kg
1
Weight
weight_kg
29.1kg
1
Dimensions
dimensions
400 x 310 x 455mm
1
Duty cycle
duty_cycle_percent
30%
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
