✦System Processors

Client Name 1.5

Manufacturer
Zingali Acoustics
Model
Client Name 1.5
Code
GW-BO9LCM
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

12
System type
system_type
Bass Reflex
1
Frequency range
frequency_range_hz
30-20000Hz
1
Sensitivity
sensitivity_db
97dB (1W/1m)
1
Nominal impedance
nominal_impedance_ohm
8Ω
1
RMS power
power_rms_w
500W (AES)
1
Crossover frequency
crossover_frequency_hz
700 (12 dB/oct)Hz
1
Woofer
woofer
1 x 15" (coil 75 mm)
1
Horn
horn
Omniray GZ 15"
1
Compression Driver
compression_driver
1" (coil 44 mm)
1
Dispersion
dispersion_deg
140 vertical (-6 dB)deg
1
Dimensions
dimensions
1120 x 520 x 730 (HxWxD)mm
1
Weight
weight_kg
75kg
1
