✦Point Source / Full-Range

E12-D

Manufacturer
d&b audiotechnik
Model
Z0602
Code
GW-XNJCZA
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Configuration
configuration
2-way coaxial (passive)
1
Drivers
drivers
12" + 1.3"
1
Max SPL
max_spl_db
133dB
1
Frequency range
frequency_range_hz
50 - 18000Hz
1
Dispersion
dispersion_deg
110° x 50° (rotatable to 50° x 110°)
1
Nominal impedance
nominal_impedance_ohm
8Ω
1
Power
power_w
300 / 1600W (RMS / peak 10 ms)
1
Weight
weight_kg
16kg
1
Dimensions
dimensions
580 x 350 x 334mm
1
Recommended amplifier
recommended_amplifier
d&b D20 / D40 / D80 (or installation 10D / 30D / 40D)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D20GW-4ECMEVD40GW-VLG5AOD80GW-W0VOZ910DGW-2VZHH230DGW-TIYI3N

d&b D20 / D40 / D80 (or installation 10D / 30D / 40D)
