✦Power Amplifiers

D40

Manufacturer
d&b audiotechnik
Model
Z2850
Code
GW-VLG5AO
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Amplifier
amplifier
4-channel Class D
1
Configuration
configuration
4 x 2400/2000W into 4/8 Ω
1
Power
power_w
2400W per channel into 4 Ω
1
Max Output Voltage
max_output_voltage
180Vpeak
1
Max Output Current
max_output_current
35Apeak
1
Weight
weight_kg
13.8kg
1
Dimensions
dimensions
2 RU x 19" x 512 mm / 20.2"
1
Input channels
input_channels
8 Milan AVB, 4 analogue (XLR), 4 AES3
1
Supported Systems
supported_systems
All current d&b loudspeaker setups except GSL, SL-SUB, J-Series, M2 (incl. KSL, V-, Y-, T-Series)
1
Power supply
power_supply
Autosensing switch mode PSU with active PFC
1
Mains Connector
mains_connector
powerCON TRUE1 TOP
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
