✦Line Arrays

GSL12

Manufacturer
d&b audiotechnik
Model
Z0751
Code
GW-OQVSQQ
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Weight
weight_kg
80kg
1
Dimensions
dimensions
391 x 1300 x 627mm
1
Max SPL
max_spl_db
149dB
1
Frequency range
frequency_range_hz
45 - 18000Hz
1
Configuration
configuration
3-way line array
1
Drivers
drivers
2x 14" front LF + 2x 10" side LF, 1x 10" MF, 3x 1.4" exit HF compression drivers
1
Dispersion
dispersion_deg
120 horizontaldeg
1
Splay Angle
splay_angle
0 - 7 in 1 incrementsdeg
1
Amplifier
amplifier
d&b D80 (2 channels per GSL12)
1
Recommended amplifier
recommended_amplifier
d&b D80 / D90
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D80GW-W0VOZ9

d&b D80 / D90
