✦Line Arrays

Q1

Manufacturer
d&b audiotechnik
Model
Q1
Code
GW-SM5YVN
Data status
Level 1 / 5
AI-parsed

❋ Specs

17
Weight
weight_kg
22kg
1
Height
height_mm
308mm
1
Width
width_mm
580mm
1
Depth
depth_mm
410mm
1
Frequency range
frequency_range_hz
60–17000Hz
1
Max Spl 1M Db
max_spl_1m_db
135–139dB SPL
1
RMS power
power_rms_w
400W
1
Peak power
power_peak_w
1600W
1
Impedance
impedance_ohm
8Ω
1
Horizontal coverage
horizontal_coverage_deg
75°
1
Vertical coverage
vertical_coverage_deg
15°
1
Vertical Splay Range Deg
vertical_splay_range_deg
0–14°
1
Material
material
marine plywood enclosure with protective coating; front panel — metal grille with replaceable acoustic foam
1
Connector type
connector_type
EP5 or NL4 (optional)
1
Drivers
drivers
2 × 10″ + 1 × 1.3″ compression driver
1
Array Capacity
array_capacity
2–20 cabinetsшт
1
Recommended amplifier
recommended_amplifier
d&b D80 / D20 / D12
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D80GW-W0VOZ9D20GW-4ECMEVCDD12GW-SLIUBH

d&b D80 / D20 / D12
