✦Line Arrays

HDL 28-A

Manufacturer
RCF
Model
13000579
Code
GW-1LECBK
Data status
Level 1 / 5
AI-parsed

❋ Specs

13
Configuration
configuration
2-way active, bi-amped
1
Drivers
drivers
2 x 8" neodymium woofer (2.5" voice coil) + 1.4" titanium compression driver (3.0" voice coil)
1
Frequency range
frequency_range_hz
50 - 20000Hz
1
Max SPL
max_spl_db
135dB
1
Dispersion
dispersion_deg
100 x 15degrees (H x V)
1
Crossover frequency
crossover_hz
750Hz
1
Amplifier
amplifier
Class D
1
Power
power_w
2200 peak / 1100 RMSW
1
DSP
dsp
48 kHz, 32 bit, FiRPHASE on-board
1
Weight
weight_kg
20.6kg
1
Dimensions
dimensions
294 x 569 x 491mm (H x W x D)
1
Input connectors
input_connectors
XLR + RDNet (EtherCon)
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers

Self-powered (built-in amplifier)
