✦Line Arrays

V12

Manufacturer
d&b audiotechnik
Model
V12
Code
GW-AEFWS2
Data status
Level 1 / 5
AI-parsed

❋ Specs

23
Frequency Range Hz Min
frequency_range_hz_min
67Hz
1
Frequency Range Hz Max
frequency_range_hz_max
18000Hz
1
Frequency Response Cut Min Hz
frequency_response_cut_min_hz
100Hz
1
Frequency Response Cut Max Hz
frequency_response_cut_max_hz
18000Hz
1
Max Spl 1M Db
max_spl_1m_db
142dB
1
Horizontal coverage
horizontal_coverage_deg
120°
1
Impedance
impedance_ohm
8Ω
1
Power Rms
power_rms
500W
1
Power Peak 10Ms
power_peak_10ms
2000W
1
Cabinets Per Amp Channel
cabinets_per_amp_channel
2шт
1
Height
height_mm
310mm
1
Width
width_mm
700mm
1
Depth
depth_mm
460mm
1
Weight
weight_kg
34kg
1
Connectors
connectors
2 × NLT4 F/M (optionally 2 × NL4)
1
Tilt Angle Range Deg
tilt_angle_range_deg
0–14°
1
Max Vertical Array Cabinets
max_vertical_array_cabinets
24шт
1
Cabinet material
cabinet_material
Marine plywood with PCP protection (Polyurea Cabinet Protection)
1
Configuration
configuration
3-way passive line array
1
LF drivers
lf_drivers
2 × 10 inches
1
Mf Driver
mf_driver
1 × 8 inches (horn-loaded)
1
HF drivers
hf_drivers
2 × 1.4 inches (compression drivers with 2.5 inch voice coils)
1
Recommended amplifier
recommended_amplifier
d&b D80 / D40 / D90 / 40D (or D20 / 30D)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D80GW-W0VOZ9D40GW-VLG5AOD20GW-4ECMEV30DGW-TIYI3N

d&b D80 / D40 / D90 / 40D (or D20 / 30D)
