✦Subwoofers

Y-SUB

Manufacturer
d&b audiotechnik
Model
Z0709
Code
GW-AZLMOU
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Configuration
configuration
Flyable cardioid subwoofer (active cardioid)
1
Drivers
drivers
1 x 18" neodymium driver (front, bass-reflex) + 1 x 12" neodymium driver (rear, bandpass)
1
Frequency range
frequency_range_hz
39-140Hz
1
Max SPL
max_spl_db
134dB
1
Weight
weight_kg
52kg
1
Dimensions
dimensions
500 x 630 x 700/804 (HxWxD)mm
1
Nominal impedance
nominal_impedance_ohm
8Ohm
1
Power handling
power_handling_w
600 RMS / 2400 peak (10 ms)W
1
Amplifier
amplifier
D20, D40, D80, D90, 10D, 30D, 40D
1
Connections
connections
2 x NLT4 F/M and 2 x NL4 M or EP5
1
Recommended amplifier
recommended_amplifier
d&b D20 / D80 (also D40 / D90; installation 10D / 25D / 30D / 40D)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D20GW-4ECMEVD80GW-W0VOZ9D40GW-VLG5AO10DGW-2VZHH230DGW-TIYI3N

d&b D20 / D80 (also D40 / D90; installation 10D / 25D / 30D / 40D)
