✦Line Arrays

Yi8

Manufacturer
d&b audiotechnik
Model
Yi8
Code
GW-USIDXZ
Data status
Level 1 / 5
AI-parsed

❋ Specs

18
Type
type
Passive 2-way line array system
1
Drivers
drivers
2 × 8" with neodymium magnet + 1.4" compression driver
1
Frequency Range Standard Hz
frequency_range_standard_hz
54 - 19000
1
Frequency Range Cut Hz
frequency_range_cut_hz
100 - 19000
1
Max Spl 1M Db
max_spl_1m_db
134 - 139 (depending on amplifier)
1
Nominal impedance
nominal_impedance_ohm
8
1
RMS power
power_rms_w
400
1
Peak power
power_peak_w
1600
1
Horizontal coverage
horizontal_coverage_deg
80
1
Vertical Splay Range Deg
vertical_splay_range_deg
0 - 14
1
Max Cabinets In Array
max_cabinets_in_array
24
1
Height
height_mm
257
1
Width
width_mm
630
1
Depth
depth_mm
375
1
Weight
weight_kg
20
1
Connectors
connectors
2 × NL4 terminal block
1
Material
material
Impact-resistant paint coating
1
Recommended amplifier
recommended_amplifier
d&b D40 / D80 (also 30D / 10D)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D40GW-VLG5AOD80GW-W0VOZ930DGW-TIYI3N10DGW-2VZHH2

d&b D40 / D80 (also 30D / 10D)
