✦Line Arrays

VTX A6

Manufacturer
JBL Professional
Model
VTX A6
Code
GW-M0SCWO
Data status
Level 1 / 5
AI-parsed

❋ Specs

18
Frequency Range 10Db Hz
frequency_range_10db_hz
67–20000Hz
1
Frequency Range 3Db Hz
frequency_range_3db_hz
80–19000Hz
1
Horizontal Dispersion 6Db Deg
horizontal_dispersion_6db_deg
110°
1
Max Peak Output Db
max_peak_output_db
134dB
1
Continuous power
power_continuous_w
350W
1
Nominal impedance
nominal_impedance_ohm
10Ω
1
Weight
weight_kg
18.4kg
1
Height In
height_in
7.5in
1
Width In
width_in
21.1in
1
Depth
depth_in
11.8in
1
Material
material
birch plywood 12mm 9-ply
1
Connector type
connector_type
speakON
1
Lf Driver Count
lf_driver_count
2
1
Lf Driver Type
lf_driver_type
JBL 2186J 6.5 in
1
Hf Driver Count
hf_driver_count
1
1
Hf Driver Type
hf_driver_type
JBL 2433H 3 in compression driver
1
Configuration
configuration
2-way passive line array
1
Recommended amplifier
recommended_amplifier
Crown I-Tech 4x3500HD / I-Tech 12000HD (V-Rack 4x3500HD / V-Rack 12000HD)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
I-Tech 4x3500HDGW-831O2DI-Tech 12000HDGW-5TZENG

Crown I-Tech 4x3500HD / I-Tech 12000HD (V-Rack 4x3500HD / V-Rack 12000HD)
