✦Line Arrays

Yi12

Manufacturer
d&b audiotechnik
Model
Yi12
Code
GW-M1MVAD
Data status
Level 1 / 5
AI-parsed

❋ Specs

21
Type
type
2-way passive line array loudspeaker
1
Weight
weight_kg
20
1
Height
height_mm
257
1
Width
width_mm
630
1
Depth
depth_mm
375
1
Drivers Woofer
drivers_woofer
2 x 8" neodymium
1
Tweeter Drivers
tweeter_drivers
1.4" compression driver
1
Nominal impedance
nominal_impedance_ohm
8
1
RMS power
power_rms_w
400
1
Power Peak 10Ms
power_peak_10ms_w
1600
1
Frequency Range Hz Min
frequency_range_hz_min
54
1
Frequency Range Hz Max
frequency_range_hz_max
19000
1
Frequency Range Cut Mode Hz Min
frequency_range_cut_mode_hz_min
100
1
Frequency Range Cut Mode Hz Max
frequency_range_cut_mode_hz_max
19000
1
Max Spl Db D10
max_spl_db_d10
134
1
Max Spl Db D25 D80
max_spl_db_d25_d80
139
1
Horizontal coverage
horizontal_coverage_deg
120
1
Splay Angle Range Degrees
splay_angle_range_degrees
0-14
1
Connectors
connectors
2 x NL4 screw terminal block
1
Channels Per Amplifier
channels_per_amplifier
2
1
Recommended amplifier
recommended_amplifier
d&b D40 / D80 (also D20; install versions 40D / 30D / 10D)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
D40GW-VLG5AOD80GW-W0VOZ9D20GW-4ECMEV30DGW-TIYI3N10DGW-2VZHH2

d&b D40 / D80 (also D20; install versions 40D / 30D / 10D)
